PCE Instruments Hardness Tester PCE-2500N

Item number: PCE_37164>

EAN: 4064343269681

Category: Measurement Technology

Manufacturer: PCE Instruments

584,90 €

Excluding 19% VAT. , plus shipping (Standard)

(including 19% VAT. 696,03 €)


2500N from PCE Instruments the measuring device of the extra class

Here in our online range you will discover incomparable measuring instruments such as data loggers, material moisture meters, anemometers, differential pressure meters and many more. By means of its new, smart technology, the 2500N ensures very accurate measurements. Our regular and also many new customers use this model in a wide range of applications. The safe housing and the modern processes guarantee quality and reliability. Convince yourself of additional features such as great flexibility due to the functional design and fast data acquisition and/or storage. Furthermore, depending on the model, you can count the following points among the equipment:

  • variable and individually adjustable measuring times
  • a user-friendly control system
  • the option of adding software for monitoring
  • a safe, robust and waterproof construction
  • and, depending on the model, much more. We will be happy to advise you.

All features of the 2500N at a glance

In addition to great flexibility, the reliable acquisition of information for analyses in the diverse work areas in laboratories and industry is playing an increasingly important role. The instrument works quickly and precisely and provides you with reproducible measurement results for your field of research. Like many of the manufacturer's other instruments, this model is battery- and/or accumulator-powered, making it easy to transport. Furthermore, it has an automatic switch-off (yes), which ensures optimised power saving. Take a look at all the details of this model:

Measuring technology type: hand-held measuring device, hardness measuring device, material testing device, durometerDisplay: LCD, backlit, OLEDWeight: 650 gDimensions (in mm): 148 x 32 x 25Power supply: rechargeable battery

For further information on the product features of the device, please contact our experts.

Get advice from the ProfiLab24 team now!

Our expert service team guarantees that you will receive the ideal equipment for your needs. Do you have questions about the different models, their features or their manufacturers?

We are extremely happy to support you and can be reached around the clock by phone at +49 (0)30-403 667 940 or by e-mail at [email protected]. We look forward to hearing from you!


Dimensions (in mm): 148 x 32 x 25
Display (metrology): backlitLCDOLED
Automatic switch off: yes
Weight, approx.: 650 g
Measurement type: DurometerMaterial testerHardness testerHand-held measuring instrument
Power supply via: Battery
Shipping weight: 1,65 Kg
Product weight: 0,65 Kg
Dimensions: × × cm
.
PCE Härtepr&strong> PCE-2500N
Measurement Ranges HLD: 170 to 960
HRC: 17.9 to 69.5
HB: 19 to 683
HV: 80 to 1042
HS: 30.6 to 102.6
HRA: 59.1 to 88
HRB: 3.5 to 101.7
Measurement accuracy HLD ±0.5%
Measurement principle Rück bounce method
Beating Type D
Display 128 x 64 OLED
Repeatability HLD: ±0.8%
Härte max1042 HV
Measuring units HLD
HRC
HB
HV
HS
HRA
HRB
LCD display 15 mm / 0.59'' screen with backlight
Material Steel
Cast steel
alloy tool steel
stainless steel
Grey cast iron
Sphäroguss
Cast aluminum alloy
brass
Bronze
Pewter Bronze
Measuring ranges on a wide variety of material surfaces
Steel HRC: 17.9 to 68.5
HRB: 59.6 to 99.6
HRA: 59.1 to 85.8
HB: 127 to 651
HV: 83 to 976
HS: 32.2 to 99.5
Tool Steel HRC: 17.9 to 68.5
HRB: 59.6 to 99.6
HRA: 59.1 to 85.8
HB: 127 to 651
HV: 83 to 976
HS: 32.2 to 99.5
Stainless Steel HRB: 46.5 to 101.7
HB: 85 to 655
HV: 85 to 802
Grey Cast Iron HB: 93 to 334
Brass HRB: 13.5 to 95.3
HB: 40 to 173
Bronze HB: 60 to 290
Copper HB: 45 to 315
Runtime lasting approx. 10 h
Power supply Rechargeable Li-ion battery
Storage conditions -30 to +60 °C
<90% RH
Operating conditions -10 to +50 °C
<90% RH
Dimensions 148 x 32 x 25 mm
Limit alarm yes
automatic shutdown yes
Weight 650 g
Scope of delivery:
  • 1 x Härteprüfer PCE-2500N
  • 1 x impact body type D
  • 1 x cleaning brush
  • 1 x Calibration block
  • 1 x Carrying case
  • 1 x instruction manual
