Dinies UV-C Air Disinfection Module LiftNclean
Item number: DINI_26019
EAN: 4064343403030
Manufacturer:
Dinies
1.490,00 €
Excluding 19% VAT. ,
plus
(Standard)
(including 19% VAT. 1.773,10 €)
Dinies UV-C Air Disinfection Module LiftNclean
The UV-C solution for lifts
Reduce risks in lifts with UV-C
- Reduce germs in the air
- Keeping the risk of infection low
Risks of infection in lifts
- The risk of infection in lifts is very high due to insufficient spacing.
- The air in the cramped transport cabins regularly becomes a carrier of disease.
- Passengers are exposed to high levels of germs in the air
- The routes of infection are short and it is easy to become infected through the air.
UV-C disinfection - What happens?
- UV-C light with a wavelength of 254nm modifies the DNA of a micro-organism and thus stops reproduction.
- If viruses or bacteria cannot reproduce, they die and are no longer infectious.
- The formation of resistance to UV-C light is impossible.
UV-C light - summary
- Disinfection up to 99.9
- Elimination of all microorganisms
- Very effective and fast disinfection method
- Free of chemicals
- Low-maintenance and cost-effective
Disinfection of the room air
- Specially designed UV-C disinfection module that automatically and continuously disinfects the room air without the use of chemicals.
- Design according to EN 81
- Disinfection takes place inside the robust housing
- Our products meet high quality standards
Advantages
- Disinfection with UV-C light eliminates up to 99.9% of all micro-organisms and is effective against SARS-CoV-2.
- The risk of infection is reduced
- The module is installed in the lift in such a way that the UV-C light can clean the air in the cabin perfectly, but does not pose any risk to passengers!
- Confidence in passengers is strengthened
Advantages over units with filters (UV-C disinfection works even without expensive filters)
- No dusty filters: Units with filters not only clean the air of viruses, but also attract dust. So the filters are very quickly clogged with house dust, hair and dirt and have to be changed.
- No infected filters: The filters are infected with viruses and must be professionally replaced regularly and disposed of properly. UV-C light disinfection does not produce hazardous waste.
- No loud background noise: Disinfection units with filters require a very powerful fan, which is correspondingly loud. With UV-C disinfection, there is (depending on the device) a non-disturbing background noise of maximum 35db.
- No costs for new filters: Due to the regular, but necessary replacement of the filters, costs arise that can be saved by the long-lasting light sources in the case of disinfection with UV-C light.
Width:
|
up to 600 mm
|
Disinfection:
|
Air
|
Areas of application:
|
LiftLiftGondolaRopeway
|
Device type:
|
filter moduleair purifierUV-C steriliser
|
Height:
|
up to 500 mm
|
Volume (UV technology):
|
32 dB
|
Air performance:
|
70 m3/h
|
Protection class:
|
IP 20
|
Depth:
|
701 mm - 800 mm
|
Dinies UV-C Air Germination Module |
LiftNclean |
Nominal voltage |
230 V, 50/60 Hz |
Nominal power |
65 W |
Dimensions (LxWxH) |
723x172x103 mm |
Ozone production (185nm) |
No |
UV-C output (254nm) |
17 W |
Air power |
70 m3/h |
Protection class |
IP 20 |
Timer |
No |
Loudness |
32 dB |
Duration of use |
Continuous operation |
People in the room |
Yes |
Disinfection of surfaces |
No |
Disinfection of air |
Yes |
Odour neutralisation |
No |
Weight |
7 kg |
Recommended temperature range |
15 to 32 °C |
Material |
Polished stainless steel |
Colour |
Silver |
Manufacturer's warranty (not on Röhren) |
12 months |
Connection |
Fixed installation |
Mounting |
Ceiling mounting
Wall mounting |
Recommended room size |
15 m2 (lift)
40 m2 (Räume) |
Operating hours |
6,000 - 8,000 hours |
Number of lamps |
2 x 20 W |
Replacement lamp |
U55-533 |
Loading slots |
Lateral |
Scope of delivery |
LiftNclean |
|
2 UV-C tubes |
|
Mounting kit |
|
Operating instructions |
